High Reliability CBB66-690VAC-25uF MPP Capacitor

$5.5

100-999
Piece/Pieces
$4.9

≥1000
Piece/Pieces

option:

Climate type：40/70/21 or 40/85 /21
Class of operation：P2(S2)/P1(S1)
Voltage range：690VAC
Test voltage terminal to terminal：1400VAC for 2 seconds
Capacitance tolerance：± 5%
I.R：≥3000S（MΩ·µF）

Contact Now

 Chat Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Model No.: YZPST-CBB66-690VAC-25μF

Brand: YZPST

Origin: China

Supply Type: Original Manufacturer

Reference Materials: Datasheet, Photo

Species: Aluminum Electrolytic Capacitor

Package Type: Surface Mount

Rated Voltage: Other

Specification: Not Applicable

Circuit Type: Isolated

Voltage-breakdown: Not Applicable

Climate Type: 40/70/21 or 40/85 /21

Class Of Operation: P2(S2)/P1(S1)

Voltage Range: 690VAC

Test Voltage Terminal To Terminal: 1400VAC for 2 seconds

Capacitance Tolerance: ± 5%

I.R: ≥3000S（MΩ·µF）

Supply Ability & Additional Information

Packaging: 1. Anti-electrostatic packaging 2. Carton box 3. braid

Productivity: 1000000000

Transportation: Ocean,Land,Express

Place of Origin: China

Supply Ability: 100000000

Port: 上海

Payment Type: L/C,T/T,Paypal

Incoterm: FOB,CFR,CIF

Packaging & Delivery

Selling Units:: Piece/Pieces

Package Type:: 1. Anti-electrostatic packaging 2. Carton box 3. braid

P/N:YZPST-CBB66-690VAC-25 μF

Features:

The capacitor takes heavy-edge metallized Al/Zn film as electrodes and dielectric. The elements are tight winded by high-velocity winders and canned in aluminum cases. Refined castor oil is adopted as impregnation agent treated in vacuum and high temperature condition. Those make a more reliable performance and longer lifespan for a capacitor. Meanwhile the second generation of mechanical anti-explosion design is selected as blast-proof secure measure for our capacitors. The reliability is more affirmatively enhanced.

Applications:

Broadly applied to starting and running of AC single-phase motors at 50Hz(60Hz) frequency for family air conditioners and high power illuminators for the sake of power factor compensation.

Technical Specifications:

Standard:IEC 60252-1:2001 Environmental protection:ROSH Technical features :

Climate type:40/70/21 or 40/85 /21

Class of operation:P2(S2)/P1(S1)

Voltage range:690VAC

Test voltage terminal to terminal :1400VAC for 2 seconds

Test voltage terminal to case :4000VAC or 3000VAC-50Hz for 60seconds

Capacitance tolerance :± 5%

I.R:≥3000S (MΩ.μF)

Dielectric dissipation factor :tgδ≤0.002 (50Hz~100Hz) Application requirements :

Altitude:≤2000m
