Mr. John chang
Model No.: YZPST-MKPH630VAC
Brand: YZPST
Origin: CHINA
Supply Type: Original Manufacturer
Reference Materials: Datasheet, Photo
Species: Polyester Film Capacitor
Package Type: Surface Mount
Rated Voltage: Other
Specification: Not Applicable
Circuit Type: Isolated
Voltage-breakdown: Not Applicable
Capacit Ance: 0.33uF
Rated Voltage: 630VAC
Ut-t: 1.6*U
Ut-c: 3000VDC
Irms: 20A
Packaging: 1. Anti-electrostatic packaging 2. Carton box 3. braid
Productivity: 10000000000
Transportation: Ocean,Land,Express
Place of Origin: CHINA
Supply Ability: 1000000000
Port: SHANGHAI
Payment Type: L/C,T/T,Paypal
Incoterm: FOB,CFR,CIF
| DESCRIPTION | VALUE | TEST CONDITIONS | ||
| Capacit ance
| Rated Capacitance | 0.33uF | Measuring frequency: 1kHz±10% Measuring voltage: 1Vrms. | |
| Capacitance olerance | J=±5% | |||
| Voltage | Rated voltage | 630VAC | 1.6*1.4*UR Unit:VDC (5 S at 20℃) | |
| Voltage proof |
| |||
| Dissipation factor (tangent of loss)
| DF≤0. 1% 1KHz 1V DF≤0.2% 10KHz 1V | Measuring frequency:1kHz±10% Measuring voltage: 1Vrms. | ||
| Insulation resistance | C≤0.33uF C＞0.33uF | IR≥30000M Ω IR*C≥5000S | measured at rated voltage or less than 100VDC 1 minute at 20℃ and RH≤65% | |
| （Ut-t） | 1.6*U | Unit:VDC (10 S at 20℃) | ||
| （Ut-c） | 3000VDC | Unit:VAC (60S at 20℃) | ||
|
| ||||
|
| ≤100fit |
| ||
|
| <2000M |
| ||
| Climatic catalogue | 40/85/21 |
| ||
| Reference standard | IEC61071 GB/T17702 |
| ||
| （Irms） | 20A | 70℃ | ||
Product Categories : Other Capacitors
